Anti-Static PCB Magazine Rack – ESD Safe Storage Solution for Electronics Manufacturing
| Description | HZ-2607 |
| Contour Size | (L×W×H)mm: 460*400*563 |
| Storage slot | 50pcs of Plates can be stored |
| The specification of PCB plates | 460*(50－330)mm |
| Guide slot of side plate | Depth 4mm, Width 5.5mm, Pitch 10mm |
| Material | Top and bottom Base are metal base |
| Fix method | Screw or gear track adjustable |
| Side plate | Five pieces assembled |
| Weight | 8.0KG |
| Temperature | 80 ℃,120℃ and 200 ℃ are available. |
| Aluminum alloy material side plate is available | |
This ESD PCB Magazine Rack provides a secure and organized solution for handling and storing printed circuit boards during production processes.
Made from conductive polypropylene side panels and aluminum frame, the rack effectively protects PCBs from electrostatic damage and mechanical stress.
Designed for use in SMT production lines, wave soldering, and assembly workshops, this rack features adjustable guide slots to accommodate different PCB widths. It’s ideal for use in ESD-controlled environments, ensuring compliance with static-sensitive handling procedures.
💡 Product Highlights:
Constructed with ESD-safe materials
Holds multiple PCBs securely
Adjustable width via screw knob or gear system
Lightweight, durable, and corrosion-resistant
Suitable for automated and manual handling systems
Easy to assemble, clean, and maintain
Size Chart:
| Model | Outer size(mm) | PCB plate size(mm) | Base material | Adjust type | Temp. | Slots |
Weight (KG) |
| HZ-2601 | 355*315*580 | 355*(80-250) | Plastic | Screw adjust. | 80℃ | 50 | 5 |
| HZ-2602 | 355*315*305 | 355*(80-250) | Plastic | Screw adjust. | 80℃ | 25 | 3.4 |
| HZ-2603 | 355*320*563 | 355* (50-250) | Metal | Screw / gear track | 80℃/120℃/200℃ | 50 | 5 |
| HZ-2604 | 355*320*563 | 355* (50-250) | Plastic | Gear track | 80℃/120℃ | 50 | 4.5 |
| HZ-2605 | 355*320*563 | 355* (50-250) | Metal | Screw / gear track | 80℃/120℃ | 50 | 6.5 |
| HZ-2606 | 355*320*563 | 355* (50-250) | Metal | Gear track | 80℃/120℃ | 50 | 6 |
| HZ-2607 | 460*400*563 | 460*(50-330) | Metal | Screw / gear track | 80℃/120℃/200℃ | 50 | 8 |
| HZ-2608 | 535*460*570 | 535*(50-390) | Metal | Screw / gear track | 80℃/120℃ | 50 | 10.5 |
| HZ-2609 | 535*530*570 | 535*(120-460) | Metal | Screw / gear track | 80℃/120℃ | 50 | 12 |
| HZ-2610 | 630*530*570 | 630*(50-460) | Metal | Screw adjust. | 80℃ | 50 | 13 |
| HZ-2611 | 355*320*560 | 355* (50-250) | Plastic | Chain adjust. | 80℃ | 50 | 6 |
| HZ-2612 | 355*320*560 | 355*(80-250) | Metal | Screw / gear track | 550℃ | 50 | 6.8 |
| HZ-2613 | 400*320*563 | 400*(50-250) | Metal | Screw / gear track | 80℃ | 50 | 6 |
Total Customize Available
Herzesd is a professional supplier of full-range ESD products and custom static protection for electronics, labs, and industrial environments.
