For anti static flooring, in a high traffic area, such as an electronics manufacturing, data center or cleanroom, care needs to be taken in the selection of the floor. The flooring material should offer uniform electrostatic discharge protection, resist heavy equipment, repeated cleaning and heavy foot traffic. When buying anti static floor, it is very important to know how to pick the good quality from not so good anti static floor.
Compliance with International ESD Standards
Firstly, for any B2B buyer, it is crucial that the product meets the international standards for ESD. Anti static flooring systems need to have a surface resistance of 10⁶ to 10⁹ ohms as specified by IEC 61340-5-1 and ANSI/ESD S20.20. These are the minimum requirements to protect sensitive electronics from damage due to ESD.
There are no on and off compliance to regulations. The conductivity may vary with changes in environment and performance should not vary due to temperature and humidity changes on the floor. Good anti static flooring should have an acceptable ESD resistance across a range of humidity to ensure an ESD protection for the life of the floor.
For B2B buyers, verified compliance documents help to ensure quality for customers and regulators, and make audits easier. As part of the supplier evaluation process, the supplier should provide the supplier test reports and certification documents if the supplier is providing a product.
Durability and Load-Bearing Capacity
Heavy duty in industrial buildings means that floors receive a heavy duty of use. When choosing a surface material for B2B, it is important to take into account the load-bearing capacity of the floor system as well.
This means that the longer the lifespan the thicker the wear layer. Anti static floors are rated at 2.0mm or higher which can last up to five times longer than the standard anti static floor of 1.0mm and can last up to 50% longer in high traffic areas. Load capacity is a factor when using a forklift, AGV or heavy machinery. Some Modular Systems are rated for 1500 kg vehicle for adhesive strength, 5000 kg vehicle + 3000 kg load when bonded.
Raised access flooring systems have even higher load capacities. It is possible to apply concentrated loads of more than 318 kg and uniform loads of more than 12,500 N/m² to ceramic anti static flooring with steel-reinforced construction. In the case of B2B buyers requiring data centers or heavy manufacturing, these specifications will make a difference in how safe operations will run, and in how much equipment will be protected.
Ease of Maintenance and Long-Term Performance
The total cost of ownership of anti static flooring can be greatly influenced by maintenance needs. B2B buyers expect solutions that are ESD compliant, have minimal maintenance requirements.
The kind of washing substance is crucial. Typical commercial cleaners leave behind insulating residue which can hinder static dissipation. There are also products that are wax-based that provide a non-conductive surface over the floor surface, and can pass the ESD test, but the floor itself is not clean. Good anti static flooring systems should only require application of pH neutral cleaners that don't leave a residue that may compromise conductivity.
There are some premium vinyl systems that have inbuilt dirt-repellant characteristics and for this reason, you don't need an application of wax and can maintain the system less often. It is important in high traffic areas where cleaning daily is essential, to take into consideration flooring that will not breakdown with frequent cleaning.
Seamless Installation and Minimal Disruption
The process of flooring installation is an important factor when running a facility that needs to be operational during installation. B2B buyers want systems that can be set up in a timely fashion with little stoppage on production.
Modular anti static flooring systems have many benefits in this respect. PVC Tiles can be made to interlock without any tools and can be individually customized, and can be easily replaced if damaged. It is a puzzle-system approach which is especially appropriate for electronics manufacturing and laboratory environments where flexibility and rapid reconfiguration is appreciated.
The phased installation capability enables the facilities to be divided into important areas, and be installed in one night, then restored operations with minimum interruption . This flexibility can make all the difference for B2B buyers who have to juggle production schedules and facility upgrades.
Shanghai Herzesd Industrial Co., Ltd. can supply a full anti-static flooring solution for the electronics manufacturing industry to meet its difficult needs. Herzesd has been in the international trading business for more than 10 years providing compliant IEC 61340-5-1 and ANSI/ESD S20.20 effective ESD protection and solutions that B2B buyers can rely on. Contact us if you have an anti static flooring requirement.
